Audit of INTMAX's zERC20

Introduction

On December 8th, 2025, zkSecurity began a security audit of INTMAX’s zERC20 privacy-preserving token system. The audit lasted two weeks with two consultants. We reviewed the zERC20 repository at commit 69537e95, corresponding to the zk-audit-target release.

This is zkSecurity’s first audit of the zERC20 system. The zERC20 protocol enables private ERC-20 transfers using a proof-of-burn mechanism: users burn tokens to special addresses derived from Poseidon hashes, then generate zero-knowledge proofs (Nova IVC or Groth16) to withdraw tokens to any recipient without revealing the sender-recipient link.

Scope

The audit focused on circuit correctness and the Solidity application logic integrating the proof-of-burn system.

Circuit Side (R1CS):

We reviewed the following Rust circuits and their associated gadgets:

• circuits/withdraw.rs, circuits/root_transition.rs, circuits/burn_address.rs: Core proof-of-burn step circuits
• utils/tree/gadgets/: Merkle proof verification, leaf hash computation, SHA-256 hash chain gadgets
• utils/poseidon/: Poseidon hash gadgets and circom-compatible bindings
• nova/withdraw_nova.rs, nova/root_nova.rs: Nova FCircuit wrappers defining public IO layout
• groth16/withdraw.rs: Single-withdrawal Groth16 circuit

We also reviewed witness generation utilities (utils/tree/merkle_tree.rs, utils/tree/incremental_merkle_tree.rs) and field encoding assumptions (utils/convertion.rs) as part of circuit correctness verification.

Solidity Side:

We reviewed the following contracts and libraries:

• Verifier.sol: Main proof verification and teleport logic
• Hub.sol: Cross-chain Poseidon aggregation hub
• zERC20.sol: ERC-20 token with SHA-256 hash chain commitment
• utils/: Hash chain, GeneralRecipient, and Poseidon aggregation libraries

The following components where considered out of scope:

• Sonobe prover internals (nova/params.rs)
• Generated Groth16 verifiers (verifiers/WithdrawGlobalGroth16Verifier.sol, verifiers/WithdrawLocalGroth16Verifier.sol)
• Generated Nova/CycleFold decider contracts
• liquidity/LiquidityManager.sol, liquidity/Adaptor.sol: Wrap/unwrap flows and OFT compose handling
• libraries/FeeLib.sol: Fee calculation math

Summary and Recommendations

The codebase was found to use sound architecture and good coding practices. Security-critical constraints such as overflow prevention in the BN254 field are well implemented. No critical issues were found in the zero-knowledge circuits in scope for this audit. The issues identified relate primarily to documentation, configuration, and privacy model clarity. It is particularly important to document and highlight the expected privacy guarantees so that end users avoid risks related to misuse of the system, such as potential indexer query leakage or anonymity set reduction (see findings below). Minor improvements to documentation and code comments can improve readability and ensure the documentation reflects the current implementation.

Additionally, the security of the smart contract owner keys is critical and should be treated as such. At present, there is no decentralized governance in place, and the owner has essentially unrestricted privileges, including upgrading contracts, minting arbitrary amounts of zERC20s, and burning tokens from any address. As a result, a compromise of the owner key would be catastrophic for the system. The owner key should therefore be protected with the strongest possible operational security (including clear documentation of the corresponding internal procedures), and the introduction of a more decentralized governance mechanism should be strongly considered to reduce this single point of failure.

Deployment Consideration: LayerZero Security Stack Configuration

While outside the core audit scope, we note that the deployment scripts (contracts/script) do not include configuration for LayerZero’s DVN and block confirmation settings. zERC20 will deploy to chains with varying finality: BSC’s FastFinality settles in seconds, while Arbitrum and Base require a 7-day challenge period. Without explicit configuration, LayerZero applies default settings insufficient for optimistic rollups. If a burn is treated as final before the challenge period ends, a reorg or fraud proof could revert it while the destination mint remains finalized, causing double-spending and inflation.

We recommend configuring finality periods per chain: 180 seconds for BSC (to handle FastFinality failures) and the full 7-day period (302,400 blocks) for Base and Arbitrum. The chosen LayerZero Security Stack configuration should be documented in detail.

Protocol Overview

The zERC20 system is a privacy-preserving wrapped token that enables unlinkable transfers across EVM chains. The core mechanism is proof-of-burn: senders burn tokens to cryptographically derived “stealth” addresses, and recipients later prove knowledge of the corresponding secret to mint tokens on the same or a different chain. On-chain observers see burns to opaque addresses and mints to recipients, but cannot correlate them. Regular (non-private) transfers are also possible.

The system consists of several coordinated components. The zERC20 token contract maintains a SHA-256 hash chain that commits to every transfer, providing a compact on-chain summary that zero-knowledge proofs can reference. An off-chain indexer tracks all transfer events and maintains a Poseidon Merkle tree of transfer leaves. When users want to withdraw, they generate either a Nova IVC proof (for batched withdrawals) or a Groth16 proof (for single withdrawals) demonstrating they know secrets corresponding to burns in the tree.

Cross-chain functionality is handled through LayerZero messaging. Each chain runs a Verifier contract that validates proofs and tracks withdrawals. A central Hub contract aggregates transfer roots from all chains into a global Poseidon tree, enabling recipients to withdraw on any chain using a “global” proof that references the aggregated state. Users can also use “local” proofs that only reference a single chain’s transfer root, trading cross-chain flexibility for faster finality.

The LiquidityManager contract handles the wrapping and unwrapping of underlying ERC-20 tokens into zERC20, implementing fee curves that incentivize liquidity rebalancing. An Adaptor contract integrates with LayerZero’s OFT standard, enabling composed cross-chain operations where tokens are transferred, unwrapped, and bridged in a single transaction flow.

Proof-of-Burn Mechanism

The proof-of-burn mechanism, based on the concept proposed in EIP-7503: Zero-Knowledge Wormholes (Private Proof-of-Burn), enables private transfers by breaking the on-chain link between senders and recipients. Instead of transferring directly to a recipient, senders transfer tokens to a cryptographically derived “burn address” that only the intended recipient can later claim. The burn address is an Ethereum address (160 bits) that no one controls directly; tokens sent there are effectively locked until claimed via a zero-knowledge proof.

Burn Address Generation

Burn addresses are derived using the Poseidon hash function with a domain separator:

burn_address = truncate_160(poseidon3("burn", recipient_hash, secret))

Where:

• "burn" is a 4-byte domain separator padded to 32 bytes and interpreted as a field element
• recipient_hash is the GeneralRecipient hash identifying the intended recipient and target chain
• secret is a random field element known only to the sender and shared with the recipient

The result is truncated to 160 bits to produce a valid Ethereum address. Additionally, a 16-bit proof-of-work constraint requires that bits 160-175 of the full Poseidon output are all zero. This is enforced by the circuit (circuits/burn_address.rs) and requires the sender to grind through approximately $2^{16}$ nonce values to find a valid secret. The PoW serves to rate-limit burn address generation and raises the cost of birthday collision attacks on the 160-bit address space from approximately $2^{80}$ to $2^{96}$ operations.

Privacy Model

The privacy guarantee is sender-recipient unlinkability: an observer monitoring the blockchain sees transfers to opaque burn addresses and later sees withdrawals to recipient addresses, but cannot determine which burns correspond to which withdrawals.

What is public:

• Burn transactions: sender address, burn address (opaque), and transfer value
• Withdrawal transactions: recipient address, withdrawal value, merkle root used
• The SHA-256 hash chain committing all transfers
• Timing of burns and withdrawals

What is hidden:

• The link between a specific burn and its corresponding withdrawal
• The secret preimage used to derive the burn address
• Which specific leaves in the merkle tree are being claimed (partially hidden; see below)

Trust assumptions and constraints:

• Contract operators: The core contracts (zERC20, Verifier, Hub, LiquidityManager) are upgradeable. Users must trust the deployer who sets immutable parameters and initial deciders/verifiers, as well as the upgrade/owner roles on each contract. Malicious upgrades could compromise funds or privacy.
• Amount correlation: The protocol does not hide transfer amounts. Unique values are trivially linkable between burns and withdrawals. Users must mix standard denominations or use partial withdrawals to achieve meaningful privacy.
• Indexer privacy: The indexer service that tracks burns and builds the Merkle tree knows which leaves a user requests proofs for. If the indexer logs query patterns, it can link senders to recipients (see finding on indexer linkability).
• Trusted setup: The Groth16 proof path requires a trusted setup ceremony. The current parameter generator uses a fixed seed, which is unsafe for production. A properly conducted multi-party computation ceremony is assumed for production deployment.

Hash Chain

Each zERC20 token maintains a hashChain value, which contains a single uint256. The hash chain is computed by the below formula:

hashChain := SHA256(hashChain || fromAddress || toAddress || value) & ((1<<248) - 1)

Note that the hash is truncated to 248 bits from 256 bits for BN254 compatibility.

Additionally, the value will be updated for each transaction in the contract. This will be used when the Verifier contract verifies the soundness of the root transition, where they will be attached with the two ends of the hash chain to ensure that the merkle tree is correctly updated.

Merkle Tree

Each of the verifier contracts maintains a Merkle tree which contains all the transactions for their corresponding zERC20 token, where each node contains (fromAddress, toAddress, value) and the tree are hashed using Poseidon.

The Merkle root can be maintained by calling the proveTransferRoot function inside the verifier contract. If a prover wants to update the Merkle root, they are required to provide a zero-knowledge proof that the two ends of the hash chain is correct, and it is up-to-date with the zERC20 token.

Zero-Knowledge Proof System

There are two ways to withdraw zERC20 tokens using the Verifier contract, teleport and singleTeleport. They are respectively using different proof systems: Nova IVC and Groth16.

• teleport (using Nova IVC) allows user to withdraw one transaction from the Merkle tree, which has the best privacy among the available transaction methods to the zERC20 token. One would be able to withdraw an arbitrary amount that is sent to the recipient by proving inclusion of an arbitrary amount of transactions that direct to the recipient on the Merkle tree. Additionally, it is possible to reduce by a certain amount by adding dummy nodes with a negative amount to improve anonymity.
• singleTeleport (using Groth16) and a lightweight proof will be used during the process. This would be less private because only one transaction is allowed, but it is much faster to generate a Groth16 proof.

Smart Contracts and Cross-Chain Architecture

LayerZero Primer

LayerZero is a cross-chain messaging protocol that enables contracts on different chains to interact with one another. Each LayerZero-supported chain hosts a LayerZero endpoint. An application that wants to use LayerZero for cross-chain messaging can register with that endpoint, specify which remote endpoints it trusts, and use the endpoint to send and receive payloads.

To make integration with the protocol easier, LayerZero provides a pre-built contract that applications can inherit from, and that implements the core interface for calling LayerZero’s endpoint: the OApp (which stands for “omnichain application”).

For tokens, LayerZero offers a special kind of OApp: the OFT (omnichain fungible token). An OFT is an ERC20 contract built on top of LayerZero’s OApp functionality. On send, it burns locally. On receive, it mints on the destination. During such a transfer, the total supply of an OFT is always preserved across chains. OFTs use the same endpoint path and configuration as any other OApp.

It’s important to note that all zERC20 tokens are, in particular, OFT tokens in the sense of LayerZero. This means that zERC20s are not only capable of private cross-chain teleports via their proof-of-burn capabilities, but can also serve public cross-chain transfers via their built-in LayerZero OFT functionality.

For a more in-depth introduction to the LayerZero protocol, we recommend the following article.

Core Contract Architecture

The smart-contract layer of the zERC20 protocol consists of three primary contracts:

Each zERC20 token will have the following setup:

• One zERC20 contract per supported chain.
• One Verifier contract per supported chain.
• One Hub contract, deployed to only a single one of the supported chains.

For example, suppose that there is a zERC20 token called “zUSD”. Further, let’s say that zUSD is supported on three chains: Base, Arbitrum, and BNB Chain. In that case, the zUSD protocol would be comprised of:

• Three zERC20 contracts.
• Three Verifier contracts.
• One Hub (e.g., on BNB Chain).

The following diagram illustrates an example setup of the core contract instances that would power an ecosystem of four different zERC20 tokens. Notice that in this example, zToken A is only supported on Chain X and Chain Z, while the other zTokens are supported on all three chains.

A Note on Contract Ownership and Upgradability

zERC20, Verifier, and Hub each set an owner during initialization. That owner is the only entity with control over certain admin functions (see the sections that follow for more info on these functions).

All three follow the UUPS pattern and gate their _authorizeUpgrade function with an owner check. In other words, upgrades are possible only through the owner key. Practically, this means that owner compromise not only allows the attacker to call admin functions, but also to swap contract logic at will.

A particular area of concern in the context of upgradable proxies are storage collisions. To reduce storage collision risk across upgrades, each contract follows the ERC-7201 namespaced storage layout. At the time of the audit, this layout choice is the recommended best practice. In particular, it is superior to earlier approaches such as storage gaps.

zERC20

zERC20 represents the main token contract of the zERC20 protocol, i.e., it represents the actual asset. Beyond the standard ERC20 token functionality, its purpose is to record a deterministic history of every transfer. Each token transfer updates a SHA256 hash chain over (from, to, value) and bumps a monotonically increasing index, so the verifier can associate proofs with a specific state of the token.

More specifically, the contract has the following key state variables:

• hashChain and index track the committed transfer history
• totalTeleported tracks cumulative mints that came from “teleport” proofs
• verifier is the verifier contract that’s associated with this token contract

Besides the standard ERC20 interface, zERC20 comes with a teleport function:

function teleport(address to, uint256 value) external {
    if (msg.sender != verifier()) revert OnlyVerifier();
    ZERC20Storage storage $ = _getZERC20Storage();
    _mint(to, value);
    $.totalTeleported += value;
    emit Teleport(to, value);
}

This function is essentially just a minting function as it mints a specific value to the to address. Beyond that, it only accumulates the totalTeleported and emits a dedicated Teleport event. The most important property of this function is its access control: only the zERC20’s dedicated verifier contract is allowed to call this function. In other words, the only way for users to “teleport” zERC20 tokens to their account is to go through the corresponding verifier contract with a valid proof-of-burn ZKP for the requested teleport.

On the LayerZero side, zERC20 implements the Omnichain Fungible Token (OFT) standard. In other words, in addition to the privacy-preserving “teleport” functionality, every zERC20 token also comes with the option to (publicly) transfer tokens cross-chain via LayerZero’s OFT protocol.

Another important implementation detail is zERC20’s custom transfer hook, _afterTokenTransfer:

function _afterTokenTransfer(address from, address to, uint256 value) internal override(ERC20Upgradeable) {
    if (value > type(uint248).max) revert ValueTooLarge();
    ZERC20Storage storage $ = _getZERC20Storage();
    super._afterTokenTransfer(from, to, value);
    $.hashChain = ShaHashChainLib.compute($.hashChain, from, to, value);
    emit IndexedTransfer($.index++, from, to, value);
}

It reverts if a value exceeds the 248-bit bound of the ZKPs, updates the hash chain, and emits IndexedTransfer while incrementing index. Note that this hook runs for all token movements, so that it’s guaranteed that the hash chain is always complete.

Besides the verifier-gated teleport, the zERC20 contract comes with several additional access-controlled functions. These are:

• setVerifier: Allows the owner to set a new verifier that is allowed to relay teleport mints.
• setMinter: Allows the owner to set a “Minter” contract, which is allowed to mint and burn tokens outside of the normal teleport flow.
• mint: Allows the minter to mint a value of tokens to a to address.
• burn: Allows the minter to burn a value of tokens from a from address.

A few comments are in order: In the future, the minter role will most likely be held by a LiquidityManager contract, which allows users to wrap/unwrap a given zERC20 against a fixed collateral asset, e.g., USDC. This way, users can “lock” their USDC in the LiquidityManager and will receive a corresponding amount of “zUSDC” from the LiquidityManager. This zUSDC payout will be facilitated through a call to the zERC20’s mint function. Similarly, if a user wants to convert their zUSDC back to the original USDC asset, they can “unwrap” their zUSDC in the LiquidityManager, which will then call burn to burn the zUSDC of the user while paying out the locked, underlying USDC in exchange. However, this user flow is still experimental and was not part of the audit scope, which is why we won’t explain it here in greater depth.

The only thing worth emphasizing here is the fact that the owner can set themselves as the minter and, therefore, mint to and burn from any address at will. For this reason, it’s crucial that the owner key is carefully protected.

As already explained in the previous sections, each zERC20 token will be realized as one-per-supported-chain deployments of the zERC20 contract. So, for example, a “zUSD token” with cross-chain support for Chain X, Y, and Z, would need one zERC20 deployment on each of the three chains.

Verifier

Every zERC20 instance comes with a corresponding Verifier contract. The main purpose of this contract is to gate teleports. More specifically, for users to be able to mint zERC20 tokens via a teleport, they need to provide a valid proof-of-burn ZKP to the Verifier.

The Verifier offers users two different ways to do teleports:

1. The teleport function handles multi-note Nova proofs, and allows users to do batch withdrawals.
2. The singleTeleport function handles Groth16 single-note proofs, which allows users to withdraw funds corresponding to a single burn.

After successful verification, both of these functions internally call zERC20.teleport to mint zERC20 tokens to the recipient.

It’s important to note that the hinted root can be either a local proved root or a Hub-derived global root. To indicate whether the provided ZKP references a teleport that is local (i.e., happens on the same chain) or global (i.e., cross-chain), users specify the boolean input isGlobal of teleport or singleTeleport, respectively.

On the LayerZero side, the Verifier extends LayerZero’s OAppUpgradeable. The main reason for this is that every Verifier needs to sync their local state with the global state that is tracked on the Hub. More specifically, each Verifier contract periodically sends its latest proved transfer root to the Hub via LayerZero. In the opposite direction, each verifier’s _lzReceive hook periodically accepts the global root from the Hub. As explained earlier, with these global roots synced, users can teleport cross-chain by specifying isGlobal = true when calling teleport or singleTeleport.

Lastly, the Verifier contract sets a contract owner upon initialization, who can upgrade the contract and has access to certain admin functionality. Concretely, the owner can call activateEmergency to pause the verifier contract’s teleport functionality. Similarly, the owner can call deactivateEmergency to return to normal operation. Moreover, the owner can reset the Nova/Groth16 ZKP verification contracts that the Verifier is using under the hood.

Hub

For a given zERC20 token, the Hub is the central LayerZero OApp that keeps one leaf per registered token instance and periodically aggregates all leaves (i.e., the local transfer roots) into a global Merkle root that the local Verifier contracts consume to stay in sync with the global state. Besides the local transfer roots that it stores in the transferRoots array, it also stores the token info (chainId, eid, verifier address, and token address) for each local instance of the zERC20 token in question. The Poseidon-aggregated global root can hold a maximum of 64 leaves, i.e., 64 is the maximum number of chains the Hub can support for a given zERC20 token.

Like the Verifier and zERC20 contracts, the Hub contract also sets an owner upon deployment. After deployment of the hub, this owner can register the local instances of the given zERC20 token via registerToken, which fixes the token instance’s leave position in the global Merkle tree. Furthermore, the owner can update the token info of a given instance, using the updateToken function.

As previously explained, the hub periodically receives new local transfer roots from the Verifier contracts. These incoming messages from the verifiers land in _lzReceive, which updates the transferRoots array of the Hub contract. However, the hub does not only receive messages from the verifiers, it also broadcasts messages to them. More specifically, the hub periodically broadcasts the aggregated globalRoot to each supported chain’s Verifier instance via LayerZero. In other words, each chain’s Verifier feeds its latest proved root upward, the Hub aggregates them, and the aggregated roots flow back down so verifiers can serve global, cross-chain teleports.
