Audit of Renegade's Atomic Settlement Feature

Description. In Renegade’s atomic settlement, the external party deposits tokens, exchanges, and withdraws tokens in one transaction. The withdrawal involves three ERC20 transfers: withdrawing the tokens bought by the receiver, paying the protocol fee, and paying the relayer fee. The protocol fee and relayer fee are deducted from the tokens bought by the receiver. However, due to an oversight, the relayer fee is not properly restricted in the circuit and can be larger than the amount bought by the receiver. As a result, an underflow may occur when deducting the fees.

        // The amount received by the external party after deducting the fees
        let trader_take = receive_amount - fees.total();
        transfers_batch.push(SimpleErc20Transfer::new_withdraw(
            tx_sender,
            receive_mint,
            trader_take,
        ));

In the code above, receive_amount and the fees are restricted to a 100-bit number. If an underflow occurs, it will result in trader_take being a very large value, close to U256::MAX. An attack is only possible when the total deposit of the protocol is close to U256::MAX.

At first glance, such an attack seems impossible: The protocol always withdraws the total amount of trader_take + protocol_fee + relayer_fee. If an underflow occurs, the total withdrawal amount would exceed U256::MAX, which is the maximum possible amount of ERC20 tokens. Thus, the attack seems doomed to fail.

However, the above statement is not true. Such an attack can occur. The attacker can set their relayer fee address as the protocol contract address. In this case, the relayer_fee will be transferred to the protocol itself. The total withdrawal amount will be trader_take + protocol_fee, which will not exceed U256::MAX.

Recommendations. It is recommended to use safe math in the contract when dealing with token arithmetic. For Rust, we can use checked_sub and checked_add:

        // The amount received by the external party after deducting the fees
        let trader_take = receive_amount.checked_sub(fees.total());
        transfers_batch.push(SimpleErc20Transfer::new_withdraw(
            tx_sender,
            receive_mint,
            trader_take,
        ));

If there is an upper bound ratio (e.g., 1%) for the relayer fee for the external party, it’s recommended to restrict it directly in the circuit. This also reduces the risk to the external party in case they forget to check the relayer fee.

Description. Renegade’s off-chain clients use the public blinder to index the wallet. Thus, Renegade disallows duplicated public blinder to avoid seeing conflicting wallets. Every time in wallet create, update and reblind operation, the contract checks the new wallet’s public blinder doesn’t exist, and then insert it into the public_blinder_set.

/// Marks the given public blinder as used
pub fn mark_public_blinder_used<C: CoreContractStorage, S: TopLevelStorage + BorrowMut<C>>(
    s: &mut S,
    blinder: ScalarField,
) -> Result<(), Vec<u8>> {
    // First check that the blinder hasn't been used
    let this = s.borrow_mut();
    let blinder = scalar_to_u256(blinder);
    assert_result!(
        !this.public_blinder_set().get(blinder),
        PUBLIC_BLINDER_USED_ERROR_MESSAGE
    )?;

    // Mark the blinder as used
    this.public_blinder_set_mut().insert(blinder, true);
    Ok(())
}

In wallet reblind operation, the blinder of new wallet is deterministically derived from the old wallet: [new_blinder, new_blinder_private] = CSPRNG(prev_private_wallet.blinder). However, there is no restriction on blinder when creating or updating wallet. Thus, a wallet will be blocked if someone creates the same public blinder (in wallet create or wallet update operation) in advance and inserts it into public_blinder_set. In this case the wallet cannot directly perform the wallet reblind operation again, which is the key step of order matching.

The relayer knows the private blinder of the wallet so it can perform the attack. An external attacker can also perform the attack: it can listen to the transaction mempool, get the new public blinder from unconfirmed transactions, and then frontrun the transaction to create a wallet with the same public blinder. With the atomic settlement feature, the ValidOfflineFeeSettlementStatement (which contains the new public blinder) will be sent to the external party before the transaction. Then it will be easier for the external party to perform the attack.

Note that if the attack happens, the wallet can change the blinder without restriction with a wallet update operation. This ensures that the wallet will not be blocked permanently.

Recommendations. It is recommended to add restriction on the blinder in wallet create and wallet update operation. For example, witness the blinder_seed and ensure [blinder, blinder_private] = hash("new_blinder_padding", blinder_seed) when creating or updating wallet. This ensures that the new created blinder will never conflict with the existing blinder.

Description. Renegade uses the constrain_equal_integer_ignore_fraction gadget to perform decimal rounding. According to the specifications, the rounding should be toward the floor. However, in the code, the gadget is loosely constrained and allows ceiling rounding, which can lead to micro-amount theft.

The rounding gadget is implemented as:

    /// Constrain a fixed point variable to be equal to the given integer
    /// when ignoring the fractional part
    pub fn constrain_equal_integer_ignore_fraction(
        lhs: FixedPointVar, // the precise decimal number
        rhs: Variable, // the rounding result
        cs: &mut PlonkCircuit,
    ) -> Result<(), CircuitError> {
        // Shift the integer and take the difference
        let zero_var = cs.zero();
        let one_var = cs.one();
        let one = ScalarField::one();

        let lhs_minus_rhs =
            cs.lc(&[lhs.repr, rhs, zero_var, zero_var], &[one, -*TWO_TO_M_SCALAR, one, one])?;

        // Constrain the difference to be less than the precision on the fixed point,
        // This is effectively the same as constraining the difference to have an
        // integral component of zero
        // (2^m - 1) - (lhs - rhs) > 0
        let diff = cs.lc(
            &[one_var, lhs_minus_rhs, zero_var, zero_var],
            &[(*TWO_TO_M_SCALAR - ScalarField::one()), -one, one, one],
        )?;
        GreaterThanEqZeroGadget::<{ DEFAULT_FP_PRECISION + 1 }>::constrain_greater_than_eq_zero(
            diff, cs,
        )
    }

This is actually checking 0 <= (2^m - 1) - (lhs - rhs) <= 2^{m+1} - 1, which translates to -2^m <= (lhs - rhs) <= (2^m - 1). This allows for rounding to either floor or ceiling, which can introduce vulnerabilities under certain circumstances.

Renegade uses decimal rounding in two places: calculating the fee and the matching amount.

For the fee calculation, this issue enables the relayer to obtain a larger relayer_fee by simply rounding up the relayer_fee. It may also result in relayer_fee + protocol_fee exceeding received_amount. Take the following code as an example: suppose received_amount is 1, then expected_relayer_fee and expected_protocol_fee will be small fractions. However, due to ceiling rounding, the relayer_fee and protocol_fee can become 1. This means the total fee exceeds the received_amount, and the internal party receives a negative token amount. This may cause an unintentional underflow and introduce unexpected behavior.

    /// Validate a fee take for a given relayer fee and protocol fee
    fn validate_fee_take_singleprover(
        received_amount: Variable,
        relayer_fee: FixedPointVar,
        protocol_fee: FixedPointVar,
        fee_take: &FeeTakeVar,
        cs: &mut PlonkCircuit,
    ) -> Result<(), CircuitError> {
        let expected_relayer_fee = relayer_fee.mul_integer(received_amount, cs)?;
        let expected_protocol_fee = protocol_fee.mul_integer(received_amount, cs)?;

        FixedPointGadget::constrain_equal_integer_ignore_fraction(
            expected_relayer_fee,
            fee_take.relayer_fee,
            cs,
        )?;

        FixedPointGadget::constrain_equal_integer_ignore_fraction(
            expected_protocol_fee,
            fee_take.protocol_fee,
            cs,
        )
    }

For the matching amount, this issue allows the counterparty to steal 1 unit of the token in every transaction. For example, an attacker could propose an order to buy WBTC with 0 units of USDC. If there is a match, according to the rules, the attacker should receive 0 WBTC. However, due to ceiling rounding, the attacker could receive 1 unit of WBTC. This means the attacker can swap 0 units of USDC for 1 unit of WBTC (about $0.0006 at the time of writing) for free.

Recommendations. It is recommended to modify the rounding gadget to enforce strict floor rounding.

It is also recommended to prohibit zero-swaps (buy_amount = 0 or sell_amount = 0), as these are less intuitive and may introduce unexpected behavior in the future.

Description. Renegade supports arbitrary ERC-20 tokens on the platform. Currently, there are no restrictions on the token contract, allowing users to create custom tokens and add them to the pool. The functions in a token contract may contain arbitrary logic and introduce unexpected behavior.

For example, at the last step of an atomic settlement call, the dark pool will call ERC20::transfer to transfer the purchased token to the external party. An ERC-20 token contract might embed another atomic settlement call within the ERC20::transfer function, leading to nested atomic settlement calls. Below is the resulting call stack:

--> Darkpool::process_atomic_match_settle
    --> Darkpool::verify_proof
    --> ERC20::transfer
        --> Darkpool::process_atomic_match_settle
            --> Darkpool::verify_proof
            --> ERC20::transfer
            ...

This results in reentrant execution.

Recommendations. It’s recommended to prevent reentrant execution in the contract as it may introduce unexpected behavior. Additionally, consider implementing an allowlist to restrict the platform to specific ERC-20 tokens.
